This ball valve with special tank bottom flange connection,
be welded on the tank bottom. The design of contour and
radius have effective gravity discharge function. Also smooth
taper hole and the sphere closely to the bottom, which
prevent the medium from staying at the entrance of valve.
Make sure drain smoothly.
Small fluid resistance, resistance equal to same length section of pipe
Simple structure, small volume, litht werght
Easy to operate, open and close rapidly, from fully open to fully closed only 90 degree rotation, convenient remote control.
Easy maintenance, simple structure, convenient to disassemble and replacement the seal ice seal, PTFE sealing, at fully
open or fully closed, sphere and the sealing surface of valve seat are Isolate with medium.
When medium transiting, these will not cause erosion of sealing surface.
Connection: clamp, weld, thread, flange
Size: 1*-4" Standard: 3A, DIN, SMS, IDF, RJT, BPE, ISO
