Name:
|
Manual tank bottom diaphragm valve bottom valve
|
|
Standard or Nonstandard:
|
Standard
|
|
Structure:
|
Diaphragm
|
|
Pressure:
|
Medium Pressure
|
|
Power:
|
Manual
|
|
Temperature of Media:
|
Medium Temperature
|
|
Media:
|
Water
|
|
Place of Origin:
|
Zhejiang, China (Mainland)
|
PRODUCT DESCRIPTION
|
Product Name:
|
Manual tank bottom diaphragm valve bottom valve
|
|
Valve Body Material:
|
SS316L
|
|
Seal Material:
|
PTFE + EPDM (double layer) / EPDM / SILICON / FPM (VITON)
|
|
Max. Working Pressure:
|
10Bar
|
|
Max. Working Temperature:
|
120 degree C
|
|
Availably size:
|
1/2"-2",DN10-DN50
|
|
Availably connection:
|
Clamp / weld / special connection
|
|
Availably standard:
|
3A/BPE/DIN/ISO/IDF
|
|
Operated:
|
Manual,Pneumatic
|
|
Availably structure:
|
Straight, tee, U-type, tank bottom
|
|
Control:
|
Smart valve positioner / C-TOP control / position sensor
|
|
Certificate:
|
3A/54-02 (1580), PED/97/23/EC, FDA.177.2600
|
|
Application scope:
|
Dairy,food, beverage, pharmacy, cosmetic, etc
|
