Product Name:
|
Sanitary Clamped Straight Sight Glass
|
|
Protective sleeve Material:
|
AISI 304
|
|
Gasket Material:
|
VMQ/NBR(standard) /EPDM,FPM, FDA177.2600
|
|
Working pressure:
|
5 bar to 10 bar according to sight glass size
|
|
Working Temperature:
|
-10°—120 °C(VMQ)
|
|
Availably size:
|
DN25-DN150,1"-6"
|
|
Availably connection:
|
Clamp / Weld / Thread
|
|
Availably standard:
|
DIN/ SMS/ RJT/ IDF
|
|
Surface treatment:
|
CNC lathe
|
|
Design:
|
Full bore design,attachment by self-locking nuts;360°viewing angle;can be used in vertical or horizontal position
|
|
Function:
|
Through it,operator can observe the flowing of the luquid substance clearly and precisely.
|
|
Application scope:
|
Food, pharmacy, cosmetic, Chemical, etc
|
|
Packaging Details:
|
Bubble pack for each. Outside packing are carton or plywood cases. Or as per the request of customers.
|
|
Delivery details:
|
Usually within 5-15 days after receiving T/T down payment.
|
