Hose ID
Inch
|
Part
Number
|
Description
|
Fitting
ID Inch
|
Flange
OD Inch
|
Fitting
Overall
Length
|
|
1/2
|
08HB-08FCL-SS
|
.5" Hose Barb x .5" Female Camlock, Locking, 316SS
|
1.50
|
0.39
|
3.28
|
|
3/4
|
12HB-12FCL-SS
|
.75" Hose Barb x .75" Female Camlock, Locking, Swivel, 316SS
|
2.12
|
0.63
|
2.52
|
|
1
|
16HB-16FCL-SS
|
1" Hose Barb x 1" Female Camlock, Locking, Swivel, 316SS
|
2.38
|
0.85
|
4.07
|
|
1-1/2
|
24HBL-24FCL-SS
|
1.5" Long Hose Barb x 1.5" Female Camlock, Locking, Swivel, 316SS
|
3.44
|
1.37
|
4.96
|
|
2
|
32HBL-32FCL-SS
|
2" Long Hose Barb x 2" Female Camlock, Locking, Swivel, 316SS
|
3.88
|
1.75
|
5.902-1/2
|
|
2-1/2
|
40HBL-40FC-SS
|
2.5" Long Hose Barb x 2.5" Female Camlock, Non-Locking, 316SS
|
4.38
|
2.20
|
CF
|
|
3
|
48HBL-48FCL-316
|
3" Long Hose Barb x 3" Female Camlock, Locking, Swivel, 316SS
|
5.31
|
2.76
|
7.15
|
|
4
|
64HBL-64FCL-316-NS
|
4" Long Hose Barb x 2.5" Female Camlock, Non-Locking, 316SS
|
CF
|
CF
|
CF
|
CF = Consult Factory
Also available:
HBS style barb
