Nominal Pipe
Size Inch
|
Part
Number
|
Description
|
ID
Inch
|
Fitting Face
Diameter Inch
|
Overall
Length
|
|
1/2
|
08HB-08LJFR-SS
|
.5" Hose Barb x Lap Joint Flange Insert, 316SS
|
0.38
|
1.38
|
2.29
|
|
3/4
|
12HB-12LJFR-SS
|
.75" Hose Barb x Lap Joint Flange Insert, 316SS
|
0.63
|
1.68
|
2.38
|
|
1
|
16HB-16LJFR-SS
|
1" Hose Barb x Lap Joint Flange Insert, 316SS
|
0.84
|
2.00
|
3.15
|
|
1-1/2
|
24HB-24LJFR-SS
|
1.5" Long Hose Barb x Lap Joint Flange Insert, 316SS
|
1.36
|
2.87
|
3.65
|
|
2
|
32HBL-32LJFR-SS
|
2" Long Hose Barb x Lap Joint Flange Insert, 316SS
|
1.75
|
3.63
|
4.15
|
|
2-1/2
|
40HBL-40LJFR-SS
|
2.5" Long Hose Barb x Lap Joint Flange Insert, 316SS
|
2.22
|
4.12
|
5.22
|
|
3
|
48HBL-48LJFR-SS
|
3" Long Hose Barb x Lap Joint Flange Insert, 316SS
|
2.87
|
4.98
|
5.39
|
|
4
|
64HBL-64LJFR-SS
|
4" Long Hose Barb x Lap Joint Flange Insert, 316SS
|
CF
|
CF
|
CF
|
