Name:
|
Single Fluid Sanitary Filter Housing
|
|
Place of Origin:
|
Zhejiang, China (Mainland)
|
|
Manufacturing process:
|
Stainless Steel Materials
|
|
Scope of application:
|
Wine,Mineral water,Drinking water
|
|
Surface treatment:
|
Electrical polish,Mirror polish,Sand polish ,Aicd washing,2B
|
Single Fluid Sanitary Filter is high quality sanitary grade filter which service for small flow rate.
Single Fluid Sanitary Filter have excellent surface treatment and the maximal corrosion-resistantin order to prevent the bacterial contamination.Theunique structure of the sanitary filter housing ensuresinside and outside surface have no dead corner and conforms to the requirements of GMP, The filter housing can be completely disassembled and washed, easy to operate.
Feature
• The high level of Polishing, inner surface≤0.3 um Ra, outside surfacecan meet 0.4 um.It is absolute hygienic levelpolishing
• Using strong Quick-open design, the highest operate pressure up to 1.0MPa
• Special vent valve and drain valve: thread sleeve and the tower joint keep separate, the connect hose can not rotate during pressure release and fluid discharge
• The legs of filter using strengthening screwis not easy to slide, more durable; the bottom of the legs can installadjusting screws and can adjust the height of the filter.It is convenient to use.
Application
• The pharmaceutical industry: pre filter various antibiotics liquor
• Food and beverage industry: alcohol, mineral water, drinking water filtration
